BOMCO F Series Mud Pumps
Mud Pump Wear Plate
Mud Pump Wear Plate for oilfield drilling equipment maintenance and replacement. Send part number, equipment model or product photo for quotation and compatibility support.
Application
Mud Pump Wear Plate for oilfield drilling equipment maintenance and replacement. Send part number, equipment model or product photo for quotation and compatibility support.
Supply Support
Specification matching, export packaging, WhatsApp and email communication support for oilfield buyers.
Specifications
Models and Technical Specifications
Source specification tables preserve merged cells while structured admin data remains editable.
Specification Table 1
| Spare Parts for F500, F-800/F1000 and F-1300/F1600 Drilling Mud Pumps | ||||||
|---|---|---|---|---|---|---|
| Name | Old Model | Model | Old Model | Model | Old Model | Model |
| F1300/F1600 | F-1300/F1600 | F-800/F1000 | F-800/F1000 | F-500 | F-500 | |
| Crank Assembly | AH36002-02.00 | AH1301020200 | AH1001010200 | AH33001-02.00 | AH0801010200 | AH0501010200 |
| AH37002-01.00 | AH1601020100 | AH1001010200 | AH33001-02.00 | AH0801010200 | AH0501010200 | |
| Gear-Shaft Assembly | AH36002-03.00 | AH1301020300 | AH1001010300 | AH33001-03.00 | AH0801010300 | AH34001-03.0 |
| AH37002-02.00 | AH1601020200 | AH0801010300 | AH34001-03.0 | AH0501010300 | AH35001-03.00 | |
| Slider-Head Block | AH36002-04.00 | AH1301020400 | AH1001010400 | AH33001-04.00 | AH0801010400 | AH34001-04.00 |
| Hydraulic-End Assembly | AH36002-05.00 | AH1301020500 | AH1001010500 | AH1001011100 | AH0801010500 | AH34001-05.00 |
| Main-Bearing End Cover | AH36001-02.01C.00 | AH130101020100 | AH100101020100 | AH33001-02.01C.00 | AH080101020100 | AH34001-02.01C.00 |
| Right Main-Bearing Fork | AH36002-02.01 | AH1301020201 | AH1001010202 | AH33001-02.02 | AH0801010202 | AH34001-02.02 |
| AH37002-01.01 | AH1601020101 | |||||
| Sealing Washer | AH36001-02.03 | AH1301010203 | AH1001010203 | AH33001-02.03 | AH0801010203 | AH34001-02.03 |
| Inner Retaining Ring | AH36001-02.04 | AH1301010204 | AH1001010204 | AH33001-02.04 | AH0801010204 | AH34001-02.04A |
| Outer Retaining Ring | AH36001-02.05 | AH130101020500 | AH100101020500 | AH33001-02.05.00 | AH080101020500 | AH34001-02.05.00 |
| AH37001-01.03 | AH160101010200 | |||||
| Rod Joint | AH36002-02.02 | AH1301020202 | AH1001010206 | AH33001-02.06 | AH0801010206 | AH34007-02.02 |
| AH37002-01.02 | AH1601020102 | |||||
| Setting Ring | AH36002-02.03 | AH1301020203 | AH1001010207 | AH33001-02.07 | AH0801010207 | AH34007-02.03 |
| Large ring gear | AH36002-02.04A.00 | AH130102020400 | AH1001010219 | AH33001-02.10A | AH0801010210 | AH34001-02.11A |
| Spacer | AH36001-02.12 | AH1301010211 | AH1001010211 | AH33001-02.13 | AH0801010211 | AH34001-01.13 |
| Main-Bearing Bushing (Left) | AH36002-02.06 | AH1301020206 | AH34001-01.13 | AH33001-02.14 | AH0801010213 | AH34001-02.16 |
| AH37002-01.03 | AH1601020103 | |||||
| Retaining Ring | AH36001-02.14 | AH1301010213 | AH1001010213 | AH33001-02.15 | AH0801010214 | AH34001-02.17 |
| AH37001-01.07 | AH1601010106 | |||||
| Retainer | AH36001-02.15 | AH1301010214 | AH1001010214 | AH33001-02.17 | AH0801010215 | AH34001-02.18 |
| Main-Bearing Bolt | AH36001-02.16C | AH1301010215 | AH1001010215 | AH33009-02.08 | AH0801020206 | AH34007-02.07 |
| Gasket | AH36001-02.17 | AH130101021600 | AH100101021600 | AH33001-02.20.00 | AH080101021200 | AH34001-02.15.00 |
| Eccentric Bearing | AH36001-02.19.00 | AH1301010217 | AH1001010217 | AH33001-02.22 | AH0801010216 | AH34001-02.19 |
| AH37001-01.08.00 | AH1601010107 | |||||
| Main Bearing | AH36001-02.20.00 | AH1301010218 | AH1001010215 | AH33009-02.08 | AH0801020206 | AH34007-02.07 |
| AH37001-01.09.00 | AH1601010108 | |||||
| Washer | 420501036160200000 | 420501036160200000 | AH1001010211 | AH33001-02.13 | AH0801010211 | AH34001-01.13 |
| Large Ring Gear (Connecting) | AH36001-02.10B.00 | AH130101021900 | AH1001010219 | AH33001-02.10A | AH0801010210 | AH34001-02.11A |
| AH37001-01.05B.00 | AH160101010900 | |||||
| Tong | AH36002-03.01 | AH1301020301 | AH1001010301 | AH33001-03.01 | AH0801010301 | AH34001-03.01 |
| Pinion Shaft | AH36002-03.02 | AH1301020302 | AH1001010302 | AH33001-03.02A | AH0801010302 | AH34001-03.02A |
| AH37002-02.01 | AH1601020201 | |||||
| Wear Bushing | AH36001-03.03 | AH1301010303 | AH1001010303 | AH33001-03.03 | AH0801010303 | AH34001-03.03 |
| End Cover | AH36002-03.03B | AH1301020303 | AH1001010304 | AH33001-03.04B | AH0801010304 | AH34001-03.04B |
| Sealing Washer | AH36001-03.05 | AH1301010305 | AH1001010309 | AH33001-03.09B | AH0801010309 | AH34001-03.09B |
| Sealing Washer | AH36001-03.06 | AH1301010306 | AH1001010306 | AH33001-03.06 | AH0801010306 | AH34001-03.06 |
| Bearing Bushing | AH36001-03.07B | AH1301010307 | AH1001010307 | AH33001-03.07B | AH0801010307 | AH34001-03.07B |
| Retaining Ring | AH36002-03.05B | AH1301020305 | AH1001010308 | AH33001-03.08B | AH0801010308 | AH34001-03.08B |
| Sealing Washer | AH36001-03.12B | AH1301010309 | AH1001010309 | AH33001-03.09B | AH0801010309 | AH34001-03.09B |
| Oil Box Assembly | AH36001-03.13B.00 | AH130101031000 | AH10010103000 | AH33001-03.13B.00 | AH080101031000 | AH34001-03.13B.00 |
| Oil seal | AH36001-03.08A | AH1301010311 | AH36001-03.08A | AH1301010311 | AH36001-03.08A | AH1301010311 |
| Bearing | AH36001-03.09 | AH1301010312 | AH1001010312 | AH33001-03.12 | AH0801010312 | AH34001-03.11 |
| Head Block | AH36002-04.01 | AH1301020401 | AH1001010401 | AH33001-04.01 | AH0801010401 | AH34001-04.01 |
| Upper Guide Plate | AH36001-04.02 | AH1301010402 | AH1001010402 | AH33001-04.02 | AH0801010402 | AH34001-04.02 |
| Gasket | AH36001-04.03A.00 | AH100101041700 | AH100101041700 | AH36001-04.03A.00 | AH100101041700 | AH36001-04.03A |
| Adjusting Washer | AH36001-04.04 | AH1301010403 | AH1001010418 | AH33001-04.25A | AH08010118 | AH34001-20 |
| Packing Box | AH36001-04.05 | AH1301010404 | AH1001010403 | AH33001-04.04 | AH0801010403 | AH34001-04.04 |
| Oil-Seal Ring | AH36001-04.21 | AH1301010405 | AH1001010404 | AH33001-04.06A | AH0801010404 | AH34001-04.06A |
| O-ring | 530301011900035000 | 530301011900035000 | 530301011750035000 | GB3452.1-82 | 530301011600035000 | GB3452.1-82 |
| Double Oil Seal | AH36001-04.08A | AH1301010406 | AH1001010416 | AH33001-04.24A | AH0801010414 | AH34001-04.23A |
| Shutoff Spring | AH36001-04.13 | AH1301010407 | AH1001010411 | AH33001-04.16 | AH0801010410 | AH34001-04.15 |
| Mud Guard | AH36001-04.10 | AH1301010408 | AH1001010406 | AH33001-04.08 | AH0801010405 | AH34001-04.07 |
| Extension Rod | AH36001-04.11 | AH1301010409 | AH1001010407 | AH33001-04.09 | AH0801010406 | AH34001-04.08 |
| Crosshead Pin | AH36002-04.03 | AH1301020403 | AH1001010408 | AH33001-04.10 | AH0801010407 | AH34001-04.09 |
| O-ring | 530301011250070000 | 530301011250070000 | 530301011750035000 | GB3452.1-82 | 530301011150053000 | GB3452.1-82 |
| Sealing Gasket | AH36001-04.15 | AH1301010411 | AH1001010413 | AH33001-04.20 | AH0801010411 | AH34001-04.19 |
| O-ring | 530301011600070000 | 530301011600070000 | 530301011600035000 | GB3452.1-82 | 530301011280070000 | GB3452.1-82 |
| Lower Guide Plate | AH36001-04.17 | AH1301010412 | AH1001010409 | AH33001-04.12 | AH0801010408 | AH34001-04.11 |
| Cross-Guide Pin | AH36002-04.04 | AH1301020404 | AH1001010414 | AH33001-04.21 | AH0801010412 | AH34001-04.20 |
| Head-Block Bearing | AH36001-04.19 | AH1301010414 | AH1001010415 | AH33001-04.22 | AH0801010413 | AH34001-04.21 |
| Hydraulic Cylinder Assembly | AH36002-05.01.00 | AH130102050100 | AH100101050100 | AH33001-05.01A.00 | AH050101050100 | AH35001-05.01A.00 |
| Cylinder-Cover Flange | AH36001-05.02 | AH1301010502 | AH1001010502 | AH33001-05.02 | AH0501010502 | AH35001-05.02 |
| Cylinder Cover | AH36001-05.03 | AH1301010503 | AH1001010503 | AH33001-05.03A | AH0501010503 | AH35001-05.03A |
| Board plug fork assembly | AH36001-05A.04.00 | AH130101050400 | AH36001-05A.04.00 | AH130101050400 | AH36001-05A.04.00 | AH130101050400 |
| Valve-Rod Guide (Lower) | AH36001-05A.05.00 | AH130101050500 | AH100101052200 | AH33001-05.31.00 | AH050101051800 | AH35001-05.24.00 |
| Cylinder-Cover Plug | AH36001-05A.06.00 | AH130101050600 | AH100101050500 | AH33001-05.05A | AH050101050500 | AH35001-05.05A |
| Positioning Plate | AH36001-05A.07 | AH1301010507 | AH1001010521 | AH33001-05.30 | AH0501010517 | AH35001-05.23 |
| Cylinder-Cover Seal | AH36001-05.08 | AH1301010508 | AH1001010504 | AH33001-05.04 | AH0501010504 | AH35001-05.04 |
| Manifold Nozzle | AH36001-05.09 | AH1301010509 | AH10010152300 | AH33001-05.34A.00 | AH080101050500 | AH34001-05.06.00A |
| Valve Spring | AH33001-05.16A | AH00000101 | AH00000101 | AH33001-05.16A | AH00000101 | AH33001-05.16A |
| Through-Bore Valve Assembly | AH36001-05.12A.00 | AH0000020300 | AH0000020100 | AH33001-05.17A.00 | AH0000020500 | AH35001-05.14A.00 |
| Valve-Cover Seal | AH36001-05.13 | AH1301010510 | AH1001010508 | AH33001-05.09 | AH0501010508 | AH35001-05.09 |
| Valve Cover | AH36002-05.02 | AH1301020502 | AH1001010509 | AH33001-05.11A | AH0501010509 | AH35001-05.11A |
| Cylinder-Liner Seal | AH36001-05.15 | AH1301010512 | AH1001010504 | AH33001-05.04 | AH0501010504 | AH35001-05.04 |
| Wear Plate | AH36002-05.03 | AH1301020503 | AH36002-05.03 | AH1301020503 | AH36002-05.03 | AH1301020503 |
| Cylinder-Liner Flange | AH36001-05.17 | AH1301010514 | AH36001-05.17 | AH1301010514 | AH36001-05.17 | AH1301010514 |
| Cylinder-Liner Cover | AH36001-05.18.00 | AH130101051500 | AH36001-05.18.00 | AH130101051500 | AH36001-05.18.00 | AH130101051500 |
| Piston Rod | AH36002-05.05 | AH1301020504 | AH1001010516 | AH33001-05.21A | AH0801010502 | AH34001-05.02A |
| O-ring | 530301012000070000 | 530301012000070000 | 530301013450070000 | GB3452.1-82 | 530301012900070000 | GB3452.1-82 |
| Cylinder-Liner Retaining Ring | AH36001-05.22 | AH1301010518 | AH36001-05.22 | AH1301010518 | AH36001-05.22 | AH1301010518 |
| Bimetallic Bushing | AH130102051200 | AH130102051200 | AH130102051200 | AH130102051200 | AH130102051200 | AH130102051200 |
| Clamp assembly | AH36002-05.06.00 | AH130102050600 | AH100101051900 | AH33001-05.24.00 | AH080101050400 | AH34001-05.04.00 |
| Bushing End Cover | AH36001-05.27 | AH1301010520 | AH1001010520 | AH33001-05.27 | AH0501010516 | AH35001-05.22 |
| British Piston | AH36002-05.09.00 | AH130102050800 | AH36002-05.09.00 | AH130102050800 | AH36002-05.09.00 | AH130102050800 |
| Suction Manifold | AH36002-05.12A.00 | AH130102051100 | AH10010152300 | AH33001-05.34A.00 | AH080101050500 | AH34001-05.06.00A |
| Gasket | AH36001-05.33A.00 | AH130101052300 | AH36001-05.33A.00 | AH130101052300 | AH36001-05.33A.00 | AH130101052300 |
| Valve-Rod Guide (Upper) | AH33001-05.12 | AH1001010510 | AH1001010510 | AH33001-05.12 | AH0501010510 | AH35001-05.12 |
| Apron | AH33001-05.14 | AH1001010512 | AH1001010512 | AH33001-05.14 | AH0501010511 | AH35001-05.13 |
| Intake Locking Plate | T55-1006 | T505-1006 | AH1001010525 | AH33001-05.39 | AH0801010508 | AH34001-05.10 |
| Suction Flange | AH33001-05.39 | AH1001010525 | AH1001010526 | AH33001-05.40 | AH0801010509 | AH34001-05.11 |
| Suction Flange | AH33009-05.03 | AH1001020509 | AH1001010526 | AH33001-05.40 | AH0801010509 | AH34001-05.11 |
| Discharge Locking Plate | T55-1008 | T505-1008 | AH050101051900 | AH35001-05.28.00A | T55-1008 | T505-1008 |
| Suction Air Chamber | AH33001-05.35A.00 | AH0000050100 | AH0000050100 | AH33001-05.35A.00 | AH080101050600 | AH34001-05.07A.00 |
| Suction Air-Chamber Assembly | AH33001-05.35A.00 | AH0000050100 | AH0000050100 | AH33001-05.35A.00 | AH080101050600 | AH34001-05.07A.00 |
| Bottle | AH33001-05.35A.02 | AH0000050101 | AK4535010100 | AK4535010100 | AK4535010100 | AK4535010100 |
| End Cover | AH33001-05.35B.03 | AH0000050102 | AH33001-05.35B.03 | AH0000050102 | AH33001-05.35B.03 | AH0000050102 |
| General View | AK75350200 | AK75350200 | AK4535010100 | AK4535010100 | AK4535010100 | AK4535010100 |
| Lower plug | AH33002-02 | AK75350101 | AK75350101 | AH33002-02 | AK75350101 | AH33002-02 |
| Bottle | AH33002-03.00 | AK7535010200 | AK4535010100 | AK4535010100 | AK4535010100 | AK4535010100 |
| Shell Assembly | AH33010-01.00 | AK7535020100 | AK4535020100 | AH34005-01.00 | AK4535010200 | AH34002-02A.00 |
| Cover | AH33010-02A | AK75350202 | AK45350103 | AH34005-02 | AK45350103 | AH34005-02 |
| Dual-Scale Gauge | Y60 | 380202052250006000 | Y60 | 380202052250006000 | Y60 | 380202052250006000 |
| Angle Shutoff Valves | JZR3-L8 | AK7535010002 | JZR3-L8 | AK7535010002 | JZR3-L8 | AK7535010002 |
| JA-3 Shear-Pin Safety Valve | AH33007-00 | AH0000060200 | AH33007-00 | AH0000060200 | AH33007-00 | AH0000060200 |
